Photoelectric Smoke Detector

JTY-AN-503A

Details

Parameter

1. Parameter

Power supply: DC10∽24V
lCurrent consumption: Standby current＜10uA; Alarm current＜100mA
lAlarm indication: red LED indicator and buzzer
lAlarm sound pressure: >80dB (3 meters directly in front)
lSilencing method: long press the self-test button for 3 seconds
Reset method: automatic reset after the smoke concentration is lower than the alarm threshold or manual reset by pressing the self-test button
Protection range: ≥20㎡
Operating environment: -10℃～50℃
Operating humidity: ≤95%RH, no condensation
Service life: >10 years
Dimensions: 102mm*40mm (diameter*height)
Shell material: White ABS
Product weight: about 210g
